Buyers Products Stainless Steel Flush Mount Single-Point T-handle latch assembly with Mounting Studs - L8855

Buyers Products Stainless Steel Flush Mount Single-Point T-handle latch assembly with Mounting Studs - L8855

5-inch Heavy-Duty T-handle Latch Series is offered in two different materials and mounting styles.

• Heavy-duty T-latch series is designed for work truck and trailers, truck toolboxes, cabinets, and storage chests.
• Each latch assembly includes a lock cylinder, key set, and gasket.
• The latch cam adjusts from 1-1/4 in. to 2 in. to suit a variety of panel depths
• Two finish options are available. Select either polished stainless steel or zinc-plated steel.
• Two mounting styles. Select stud-mount installation or 4 pre-drilled mounting holes.
• Overall Latch measurements are 4.75-in wide by 4.88-in tall

Product Specifications

• Gasket Included: YES
• Gasket Thickness: 0.11"
• Handle Material: Stainless Steel
• Height (in.): 4.88"
• Housing Finish: Polished
• Housing Material: Stainless Steel
• Latch Style: T-Handle
• Locking: Yes
• Maximum Cam Size: 2.00"
• Minimum Cam Size: 1.13"
• Mount Height (in.): 3.31"
• Mount Type: Stud
• Mount Width (in.): 3.88"
• Width (in.): 4.75"
• Shipping Weight: 1.22 lb
